Dual screen mode maximize your convenience and efficiency of working
Dual screen IP phone is the flagship products in IP telephone in the
world. 4.3 inch TFT color display enhance the visual image of your desktop .
innovative paperless BLF+BLA maximize your working efficiency ,
the crystal clear broadband voice ( meet TIA920 standard) bring you the
revolutionary working experience

2D graphics accelerator design improves the UI operation very smoothly

Visualized LCD for BLF maximize your working efficiency

Top level voice quality

WIFI + cable connection enable flexible deployment

Dual core CPU is the guarantee of high quality IP phone


One core for instruction process and the other core for voice
decoding greatlyimprove the sound quality and make it possible
to run more complicated applications fluently.







Specification


Basic functions
4.3" TFT LCD, 480*272 Pixel, 6 SIP accounts, Call Forward, Call Transfer, Call Waiting, Hotline, Call Hold, Auto Answer, Caller ID, Redial, Mute, DND, Local 3-Way Conferencing, Speed Dial, Voice Mail, Local Phonebook (upto 400 entries), Direct IP call without SIP proxy, Black list, White list, Dialed/Rece ived/Missed/Forward call (total 400), Call Center Headsets mode,support EHS headset




Management
Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66, Redirection and Provisioning Service(RPS)
IP PBX Features
Intercom, Paging, Call pickup, Call park, Anonymous call, Anonym ous call rejection, Hold on music, Conference Call, Group pickup, DND&Call forward state synchronization, Call Recording








Physical
Power Interface: DC 5V-1A, PoE power supply: IEEE 802.3af Class 2 2x RJ45 100/1000M adaptive Ethernet ports, 1x RJ9 headphone jack, 1x RJ9 handset jack
Mult-language
English, German, Italian, French, Spanish, Portuguese, Russian, Chinese, Arabic, Polish, Turkish , Hebrew










Keys Features
1 status indicator, 4 line keys, 4 soft keys, 5 navigation keys, 1 vo lume keys, 8 function keys (menu, cancel, hold, voicemail, mute, headphone, redial, hands-free)
Advanced Features
LDAP, Microsoft active directory(AD) server, XML remote phonebook,TR069,Action URL












Temperature and Humidity
Operating temperature: -10 ~ 50°C, Operating humidity: 10 ~ 90%
Audio Features
10( own ring tone,+ custom ring tone article), 8 volume adjustable + Mute mode, Narrowband codec: G.711(a/μ), G.729A/B/AB, G.726, iLBC, Wideband codec: G.722, L16, Support VAD, CNG, AEC, PLC, AJB, AGC, Full-duplex speakerphone with AEC




Management
Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66, Remote Provision Service(RPS)
Network Features
LAN / PC: support bridge mode, Open VPN, IPv4&IPv6,SIP connection mode: Proxy mode, and P2P mode, Support DNS SRV (RFC3263). NAT transverse: STUN mode. DTMF: In-band, RFC2833, SIP INFO, Support QoS, HTTP / HTTPS web server, Package tracing export, Syslog




Package
Qty/CTN: 10 PCS , G.W/CTN: 16KG, Giftbox size: 29 0m m(L)*200mm ( W ) *120mm(H) Carton Meas: 615mm(L) *405mm(W) *310mm(H)
WiFi Features(A68W only)
IEEE 802.11b/g/n, Enhanced support for IEEE 802.11e QoS, IEEE802.11i (WPA, WPA2) authentication








Certifications
CE: EN60950 FCC: Part15
Security
VLAN, LLDP, IEEE802.1X, TLS, HTTPS, SRTP (RFC3711), Digest authentication using MD5/MD5-sess, AES encryption for configuration files, Phone lock, User and administrator level access control




Models


A68/A68W Models PoE Wifi Gigabit


A68W Y Y Y

Downloads


Firmware User manual Brochure Datasheet Quick installation guide Cautions


Comparison



  A68/A68W A48/A48W A41/A41W A2X A1X
  LCD Display 4.3" TFT LCD 3.2" TFT LCD
400*240 Pixel
3.2" TFT LCD
224*128 Pixel
132*58 Pixel 132*52 Pixel
 2D Graphics Accelerator Yes No No No No
  Programmable keys 14 12 12 2 0
  SIP Accounts 6 4 4 2 1
  Gigabit LAN Port Yes Yes No Optional Optional
  RJ45 Ethernet ports 2(Bridge Mode) 2(Bridge Mode) 2(Bridge Mode) 2(Bridge Mode) 2(Bridge Mode)
  WIFI connection A68W only A48W only Optional
(Only A41W)
Optional
(Only A20W/A21W)
Optional
(Only A10W/A11W)
 POE Supported Yes Yes Yes Optional(A21/A21W)) Optional(A11/A11W)
  Extension Modules Yes(RET) Yes(RET) Yes(RE) No No
  Wall mount No No No Yes Yes
  Headset Yes Yes Yes Yes Yes
  HD Voice HD Voice Codec
HD Handset
HD Speaker
HD Voice Codec
HD Handset
HD Speaker
HD Voice Codec
HD Handset
HD Speaker
HD Voice Codec
HD Handset
HD Speaker
HD Voice Codec
HD Handset
HD Speaker
Speakerphone Full-Duplex
Hands-free
Talking
Full-Duplex
Hands-free
Talking
Full-Duplex
Hands-free
Talking
Full-Duplex
Hands-free
Talking
Full-Duplex
Hands-free
Talking
LDAP Yes Yes Yes Yes Yes
  BLF Yes Yes Yes No No
  BLA Yes Yes Yes No No
 XML remote phonebook Yes Yes Yes Yes Yes
  SRTP Yes Yes Yes Yes Yes
  TLS Yes Yes Yes Yes Yes
  DHCP Option 66/67 Yes Yes Yes Yes Yes
  Auto Provision TFTP/FTP
/HTTP
TFTP/FTP
/HTTP
TFTP/FTP
/HTTP
TFTP/FTP
/HTTP/HTTPS
TFTP/FTP
/HTTP
 RSP WAN deployment Yes Yes Yes Yes Yes
 Wideband Codec G.722
L16 PCM
G.722
L16 PCM
G.722
L16 PCM
G.722
L16
G.722
L16 PCM
 Narrowband Codec G.711(A/u),
G.723, G.726,
G.729AB,
iLBC
G.711(A/u),
G.723, G.726,
G.729AB,
iLBC
G.711(A/u),
G.723, G.726,
G.729AB,
iLBC
G.711(A/μ),
G.729A/B/AB,
G.726, iLBC
G.711(A/u),
G.723, G.726,
G.729AB,
iLBC

----------------------------------------
